Series image - for reference only

Part Builder Close Match Items CAD Drawings Email Item Add to Formal Quote Series Catalog Ordering Guide
Normal View Purchasing View
         -

SMC CDBG1FN25-200-HN cyl, end lock, auto-sw, CBG1 END LOCK CYLINDER

$78.00
  • Available to Ship Today*:
  • Available to Ship Tomorrow*:
  • Available to Ship in 5 Days*
  • Available to Ship in 7 Days*:
Part #: CDBG1FN25-200-HN
Series Catalog

Description

Series CG1 precision air cylinder has 8 bore sizes and can meet any application need. The tube is impact extruded aluminum to produce an extraordinarily smooth finish, allow low break-away pressure and smooth stroke action. Eight mounting options are available. Auto switch capable.

  • End lock cylinder, CBG1
  • Double acting, single rod
  • 7 mounting styles available
  • Bore sizes *: 20, 25, 32, 40, 50, 63, 80 and 100
  • Rubber bumper or air cushion standard
  • Auto-switch capability

Downloads

CAD Downloads

CAD Files from ETECH

View CAD Models

View 3D Model
Close match in stock Inventory
Some out of stock items can be obtained in 1 to 6 weeks. Contact us for more information
Price: $78.00
