Part Number Configuration Guide for Flow Controls
Use the chart below to configure your specific model. By selecting the correct body size, piping type (Meter-in/Meter-out), and port size, you can ensure the component meets your exact pneumatic system requirements.
Select based on required flow rate ($Cv$ factor). Options range from M5 miniature to 1/2" high-flow series.
Choose Meter-out (standard for double-acting) or Meter-in (typically for single-acting cylinders).
Specify thread type (NPT, R, G) and the One-touch fitting size for your tubing.
