Series image - for reference only

Part Builder Close Match Items CAD Drawings Email Item Add to Formal Quote Series Catalog Ordering Guide
Normal View Purchasing View
         -

SMC CDQ2A63-100DZ-XC35 cyl, compact w/scraper, CQ2-Z COMPACT CYLINDER

$132.10
  • Available to Ship Today*:
  • Available to Ship Tomorrow*:
  • Available to Ship in 5 Days*
  • Available to Ship in 7 Days*:

Please call 800-799-4568 or email to confirm availability.

Part #: CDQ2A63-100DZ-XC35
Series Catalog

Description

SMC has redesigned the CQ2 compact cylinder with a new body, making it possible to mount auto switches on any of the 4 surfaces, depending on the installation conditions. Auto switch mounting grooves have replaced the CQ2s mounting rails, preventing projection of auto switches and improving ease and safety of work.

  • Double acting, single rod, compact cylinder
  • Bore sizes *: 12, 16, 20, 25, 32, 40, 50, 63, 80, 100
  • Standard stroke range *: 5 to 100
  • Port threads: M *; Rc, NPT or G *
  • Auto switch capable
