SMC's?IS10 pressure switch is 16% lighter, and 11% smaller?when compared to the IS1000.? The IS10 is RoHS?compliant and CE marked.? Set pressure range is 0.1 to 0.4MPa (optional 0.1 to 0.6 MPa).? Also available are the IS10M (pressure switch with spacer) and the IS10E (pressure switch with piping adapter).
- Weight: 62g (16% lighter than IS1000)
- Overall height: 52mm (11% smaller than IS1000)
- 100V AC/DC specifications
- Service life: 5 million cycles
- Can be connected to modular type FRL units
- RoHS compliant and CE marked
