SMC CDU16-50D-M9BLS cylinder, CU COMPACT CYLINDER

The CLS series cylinder with lock is ideal for applications requiring intermediate and emergency stop and drop prevention. The compact lock unit is lightweight and saves space. A switch is optional on the brake cylinder so the operating state of the lock unit (brake piston) can be detected using the switch signal. By separating the lock mechanism and the brake cylinder, SMC has minimized the influences of unlocking air quality such as moisture and condensation.

• Fail safe construction
• Equal holding force in both directions
• Lock unit switch
• Improved maintainability
• Strokes to 1600 depending upon mounting brackets
• Auto switch capable cylinder
• Auto switch capable brake unit
