SMC KK130P-04F s coupler, female thread, KK13 S COUPLERS (sold in packages of 5; price is per piece)

S coupler series KK employs a unique connection method. A slim body design and large effective area are achieved with a construction that does not use steel balls or valve springs and therefore does not restrict the flow path. Together with a reduction of the body size, pressing parts and resin parts are used to achieve an overall weight reduction.

• Plug and socket variations: male and female thread, barb fitting, nut fitting, one-touch fitting
• Operating pressure range: 0 to 1.5MPa, one-touch fitting types : 0 to 1.0MPa
• Proof pressure: 2.0MPa
• Male thread types provided with sealant as standard
