SMC LVQ30-Z11-3-N high purity chemical liquid valve, HIGH PURITY CHEMICAL VALVE

Series LVQ is a 2 port chemical valve with a non-metallic exterior. A high density PVDF housing offers increased chemical resistance and the special diaphragm construction insures gentle opening and closing preventing the formation of micro-bubbles. The LVQ guide ring eliminates lateral motion of the poppet, which reduces internal leakage.

• 2 port chemical valve
• Non-metallic exterior
• LQ3 integral fitting
• Tube O.D.: 1/4", 3/8", 1/2", 3/4", 1", °3, °4, °6, °8, °10, °12, °19, °25
• Orifice: °4, °8, °10, °16, °22
• Cv factor: .35 to 8.0
