SMC VEX1900-20N valve, sol, VEX PROPORTIONAL VALVE

Power valve series VEX includes a regulator valve (VEX1*0), precision regulator (VEX1*3), 3 position valve (VEX3) and a economy valve (VEX5). The 3 port large capacity poppet exhausting regulator is equipped with a relief port the same size as the connection port. The 3-port, 3-position double solenoid that permits vacuum suction, vacuum destruction, and suspension (closed) is ideal for a system where many valves are used.

• Power valves series, regulator valve
• Styles: air operated, external pilot solenoid
• Port sizes (mm): 1/8, 1/4, 3/8, 1/2, 3/4, 1, 1 1/4, 1 1/2, 2
• Maximum operating pressure: 1.0MPa
• Ambient and fluid temperature: 0 to 50C
