SMC VM230-N02-02SA-B mechanical valve, MECHANICAL VALVE

Part #: VM230-N02-02SA-B
SMC VM230-N02-02SA-B mechanical valve, MECHANICAL VALVE
$25.00
Adding to cart… The item has been added

The VM series is a mechanical, poppet valve. Their compact size requires little mounting space. The VM series offers a wide variety of actuator styles and flow capacity up to 1.0 Cv.

  • Fluid: air
  • Operating pressure: 0 to 1.0MPa
  • Effective area (Cv): 19mm 2 (1.0)
  • Fluid temperature: -5° to 60°C (no freezing)
  • Port size (nominal size): Rc(PT) 1/4 (8A)
