SMC CE2D100-100 cyl, scale, CE2 MISCELLANEOUS/SPECIALIZED

The CE2 series cylinder, through prediction control and a learning feature, is capable of highly reproducible positioning (stopping accuracy of ? 0.5mm). The brake mechanism, employing a combination spring and air pressure locking system, allows locking on either of the cylinders reciprocating strokes. The CE2 measurement function, utilizing a magnetic scale rod and built-in detection head, provides a minimum unit of measure of 0.1mm.

• Brake mechanism added to stroke reading cylinder
  which can measure stroke length
• Resolution: 0.1mm
• Precision positioning (stopping accuracy ?0.5mm)
• Prevents dropping from raised positions during
  intermediate stops
• Minimum unit of measure: 0.1mm
• Bore sizes: 40, 50, 63, 80, 100
